FEATURES • Test 6V or 12V batteries, test the charging system, analyze battery condition, test starter motor on your vehicle all with one tool • Accurate color-coded volt meter with scale from 0 to 16V • Test standard lead acid vehicle batteries • 100 Amp load test suitable for testing 12 Volt batteries up to 1000CCA • 50 Amp load test suitable for testing 6 Volt batteries up to 1000CCA • Metal case and powder coated surface provides protection of the battery tester
TECHNICAL SPECIFICATIONS Measurements 315 x 180 x 94MM Weight 1.09KG Battery Test Capacity 6VDC or 12VDC Lead Acid Batteries Load Test Capacity 100Amps @ 12VDC or 50Amps @ 6VDC Amps Capacity 200 to 1000CCA (Cold Cranking Amps) Amps Setting 100Amps Display Meter Analog, 0-16VDC (Max) Voltage Range 0-16VDC Accuracy +/- 0.2VDC Test Cycle 10 Seconds Per Test (Max)
|
