Features
For single phase alternating current
Powerful and fast cutting for profiles, pipes and rods made of steel, cast iron, aluminium and other non-ferrous metals.
Motor and gear with ball bearing for high loads
Spindle lock for easy disc change
Quick clamping device with variable mitre conversion from -15° up to 45°
Easy to transport due to built-in handle and locking device
High safety thanks to swivelling cutting guard
Storage for double-ended wrench at the machine table
Safe working thanks to adjustable spark guide plate
Adjustable cutting depth limiter
Specifications
Grinding wheels (Ø x bore): 355 x 25.4 mm / 14 x 1 "
Torque: 18 Nm / 160 in-lbs
No-load speed: 4000 rpm
Rated input power: 2300 W
Cutting capacity steel bars: 65 mm / 2 1/2 "
Cutting capacity tubes: 125 mm / 5 "
Cutting capacity steel sections: 115 x 130 mm / 4 1/2 x 5 1/8 "
Maximum opening of vice jaws: 238 mm / 9 3/8 "
Dimensions of the base plate: 468 x 282 mm / 18 7/16 x 11 3/32 "
Transport height: 400 mm / 15 3/4 "
Weight: 16.9 kg / 37 lbs
Cable length: 2.7 m / 9 ft
Noise emission
Sound pressure level: 91 dB(A)
Sound power level (LwA): 104 dB(A)
Uncertainty of measurement K: 3 dB(A)
Includes
Open-ended ring spanner
Inner support flange
Flange nut
|
